Rectangular Duct to Circular Duct Calculator

1. What is a Circular Equivalent Diameter Calculator?

Definition: This calculator computes the equivalent round duct diameter (\( D_e \)) for a rectangular duct with equal flow, resistance, and length.

Purpose: It is used in HVAC design to convert rectangular duct dimensions to an equivalent circular duct diameter, simplifying pressure loss and flow calculations.

2. How Does the Calculator Work?

The calculator uses the following formula for the circular equivalent diameter:

Circular Equivalent Diameter: \[ D_e = \frac{1.30 (a b)^{0.625}}{(a + b)^{0.250}} \]

Where:

\( D_e \): Circular equivalent diameter (in., ft, m)
\( a \): Length of one side of rectangular duct (in., ft, m)
\( b \): Length of adjacent side of rectangular duct (in., ft, m)

Unit Conversions:

Side Lengths (\( a \), \( b \)):
- in.: No conversion
- ft: 1 ft = 12 in.
- m: 1 m = 39.3701 in.
Circular Equivalent Diameter (\( D_e \)):
- in.: No conversion
- ft: 1 in. = 1/12 ft
- m: 1 in. = 0.0254 m

Steps:

Enter the length of one side (\( a \)) and the adjacent side (\( b \)) of the rectangular duct, and select their units.
Convert \( a \) and \( b \) to in.
Calculate the circular equivalent diameter using the formula.
Convert the result to the selected unit (in., ft, or m).
Display the result with 5 decimal places, or in scientific notation if the value is greater than 10,000 or less than 0.00001.

3. Importance of Circular Equivalent Diameter Calculation

Calculating the circular equivalent diameter is crucial for:

HVAC System Design: Simplifies pressure loss calculations for rectangular ducts by converting them to an equivalent circular duct.
System Efficiency: Ensures accurate flow and resistance analysis, optimizing duct design and fan selection.
Performance Analysis: Enables consistent calculations across different duct shapes for effective ventilation.

4. Using the Calculator

Examples:

Example 1: For \( a = 60 \, \text{in.} \), \( b = 20 \, \text{in.} \), circular equivalent diameter in in.:
- \( D_e = \frac{1.30 \times (60 \times 20)^{0.625}}{(60 + 20)^{0.250}} \approx \frac{1.30 \times 1200^{0.625}}{80^{0.250}} \approx 36.972 \)
- Since 36.972 < 10000 and > 0.00001, display with 5 decimal places: \( 36.97200 \)
Example 2: For \( a = 1.5 \, \text{m} \), \( b = 0.5 \, \text{m} \), circular equivalent diameter in m:
- Convert: \( a = 1.5 \times 39.3701 \approx 59.05515 \, \text{in.} \)
- \( b = 0.5 \times 39.3701 \approx 19.68505 \, \text{in.} \)
- \( D_e = \frac{1.30 \times (59.05515 \times 19.68505)^{0.625}}{(59.05515 + 19.68505)^{0.250}} \approx 36.972 \, \text{in.} \)
- Convert to m: \( 36.972 \times 0.0254 \approx 0.93909 \)
- Since 0.93909 < 10000 and > 0.00001, display with 5 decimal places: \( 0.93909 \)
Example 3: For \( a = 5 \, \text{ft} \), \( b = 2 \, \text{ft} \), circular equivalent diameter in ft:
- Convert: \( a = 5 \times 12 = 60 \, \text{in.} \)
- \( b = 2 \times 12 = 24 \, \text{in.} \)
- \( D_e = \frac{1.30 \times (60 \times 24)^{0.625}}{(60 + 24)^{0.250}} \approx 38.555 \, \text{in.} \)
- Convert to ft: \( 38.555 / 12 \approx 3.21292 \)
- Since 3.21292 < 10000 and > 0.00001, display with 5 decimal places: \( 3.21292 \)

5. Frequently Asked Questions (FAQ)

Q: What does the circular equivalent diameter represent?
A: The circular equivalent diameter (\( D_e \)) is the diameter of a round duct that has the same flow and resistance characteristics as a given rectangular duct, simplifying HVAC calculations.

Q: How can I determine the side lengths of a rectangular duct?
A: The side lengths (\( a \) and \( b \)) are the physical dimensions (width and height) of the rectangular duct, measured or specified in the duct design.

Q: Why is the circular equivalent diameter important in HVAC design?
A: It allows engineers to use standard circular duct formulas for rectangular ducts, ensuring accurate pressure loss and flow calculations for system efficiency.
