Friction Loss for Duct Run Calculator

1. What is a Friction Loss for Duct Run Calculator?

Definition: This calculator computes the friction loss (\( F L \)) in a duct run, representing the pressure drop due to friction, based on the equivalent length and friction factor per 100 ft.

Purpose: It is used in HVAC design to quantify pressure losses in duct systems, aiding in fan selection and duct sizing for efficient airflow.

2. How Does the Calculator Work?

The calculator uses the following formula for friction loss:

Friction Loss: \[ F L = \frac{E Q L \times F F}{100} \]

Where:

\( F L \): Friction loss (in. of water, Pa)
\( E Q L \): Equivalent length (ft, m)
\( F F \): Friction factor, loss per 100 ft (in. of water/100 ft, Pa/100 m)

Unit Conversions:

Equivalent Length (\( E Q L \)): ft, m (1 m = 3.28084 ft)
Friction Factor (\( F F \)): in. of water/100 ft, Pa/100 m (1 Pa/100m = 0.0122833 in. of water/100 ft)
Friction Loss (\( F L \)): in. of water, Pa (1 in. of water = 248.84 Pa)

Steps:

Enter the equivalent length (\( E Q L \)) and friction factor (\( F F \)), and select their units.
Convert \( E Q L \) to ft and \( F F \) to in. of water/100 ft.
Calculate the friction loss using the formula.
Convert the result to the selected unit (in. of water or Pa).
Display the result with 5 decimal places, or in scientific notation if the value is greater than 10,000 or less than 0.00001.

3. Importance of Friction Loss Calculation

Calculating friction loss is crucial for:

HVAC System Design: Quantifies pressure losses in duct runs, ensuring accurate fan sizing and duct design.
Energy Efficiency: Minimizes energy consumption by optimizing duct layouts to reduce friction losses.
System Performance: Ensures proper air distribution for effective ventilation.

4. Using the Calculator

Examples:

Example 1: For \( E Q L = 350 \, \text{ft} \), \( F F = 0.09 \, \text{in. of water/100 ft} \), friction loss in in. of water:
- \( F L = \frac{350 \times 0.09}{100} = 0.315 \)
- Since 0.315 < 10000 and > 0.00001, display with 5 decimal places: \( 0.31500 \)
Example 2: For \( E Q L = 100 \, \text{m} \), \( F F = 22.5 \, \text{Pa/100 m} \), friction loss in Pa:
- Convert: \( E Q L = 100 \times 3.28084 \approx 328.084 \, \text{ft} \)
- \( F F = 22.5 \times 0.0122833 \approx 0.276374 \, \text{in. of water/100 ft} \)
- \( F L = \frac{328.084 \times 0.276374}{100} \approx 0.90667 \, \text{in. of water} \)
- Convert to Pa: \( 0.90667 \times 248.84 \approx 225.576 \)
- Since 225.576 < 10000 and > 0.00001, display with 5 decimal places: \( 225.57600 \)
Example 3: For \( E Q L = 500 \, \text{ft} \), \( F F = 0.12 \, \text{in. of water/100 ft} \), friction loss in in. of water:
- \( F L = \frac{500 \times 0.12}{100} = 0.6 \)
- Since 0.6 < 10000 and > 0.00001, display with 5 decimal places: \( 0.60000 \)

5. Frequently Asked Questions (FAQ)

Q: What does friction loss represent?
A: Friction loss (\( F L \)) quantifies the pressure drop due to friction in a duct run, affecting airflow and system efficiency.

Q: How can I determine the equivalent length and friction factor?
A: Equivalent length (\( E Q L \)) is the total effective length of the duct run, including fittings, calculated from design specifications. Friction factor (\( F F \)) is obtained from duct friction charts or standards (e.g., ASHRAE) based on duct material and airflow.

Q: Why is friction loss important in HVAC design?
A: It helps engineers account for pressure drops, ensuring accurate fan sizing and efficient duct system performance.
